DESCRIPTION
Small & Compact
Performance
Litemove TS-SP bike light offers 240 degrees of light visibility, providing bikers an all-around light sphere that’s visible even from the back.
Small & Compact
Dimensions & Weight:
18(H) x 17(L) x 65(W) mm; 23g
Mounting
Attach on the back of seatposts with diameters of 31.6/30.9/27.2mm.
Please make sure your seatposts are compatible before purchasing.
Notes:
- This tail light can ONLY be charged through 6V(5V ~ 16V) DC power
- Do not charge via an AC power source (e.g. a dynamo)
- Connecting to power supplies above the voltage limit may cause damage to the light
- The light does not feature a switch, It is controlled via the e-bike system
SPECIFICATION
| Model Name | TS-SP |
| Model No. | TKSESP1-316 TKSESP1-272 |
| S/N | B03 |
| Light Output | 7200mcd |
| Optical Technology | LTi |
| Light Source | LED *4 |
| Input Voltage (DC) | 6V(5V ~ 16V) |
| Power Consumption | 0.6W |
| Cable Diameter | ø3mm |
| Cable Length | 1400mm |
| IP Rating | IP56 |
| Operating Temperature (°C) | -25 ~ +70 |
| Material | Plastic |
| Weight (et. cable) | 18g (without adapter) |
| Dimension (WxHxL) | 38 x 18 x24mm (without bracket) |
| Mounting Option | TKSESP1-316: ø31.6 & 30.9mm seat post TKSESP1-272: ø27.2mm seat post |
| Reflector (Optional) | N/A |
| Compliance | CE/RoHS/ REACH/ Prop 65 |
| Type of Approval | StVZO-K & ISO-6742 |
| Approval Number | ~ K1693 |
VIDEO
BOSCH Motor
BROSE Motor
SHIMANO Motor
SYSTEM COMPATIBILITY
System Compatibility- Download
