DESCRIPTION
- The TZH tail light combines sleek design with smart safety features. Its carrier-mounted form integrates a Z-mark retroreflector, meeting German StVZO standards.
- With a 50mm mounting option, it installs easily across a wide range of bicycles.
- K-Mark certified, the TZH enhances visibility—ideal for urban riders and e-bike users who prioritize safety and style.
SPECIFICATION
Model Name | TZH |
Model No. | TZH |
S/N | 0042-1 |
Light Output | 5500mcd/16 lumens |
Optical Technology | TZH |
Light Source | LED *2 |
Input Voltage (DC) | 12V(5V ~ 16V) |
Power Consumption | 0.6W |
Cable Diameter | ø3mm |
Cable Length | 1400mm |
IP Rating | IP56 |
Operating Temperature (°C) | -20 ~ +50 |
Material | Plastic |
Weight (et. cable) | |
Dimension (WxHxL) | 70 x 21 x 14.7 mm |
Mounting Option | Bicycle carrier 50mm mount |
Reflector | Integrated Z-Reflector |
Compliance | CE/ RoHS/ REACH |
Type of Approval | StVZO-K & ISO-6742 |
SYSTEM COMPATIBILITY
System Compatibility- Download
