DESCRIPTION
Performance
Litemove SE-90 headlight provides 7m wide and up to 180m distance of beam visibility ahead. Far distance & wide view pattern that giving the rider a best visibility riding on bike path.
Small & Compact
With a size of a match box, you can easily mount them on stem/ fork or under basket without any interference to other components.
Mounting
SE-90 provides 2 different mounting positions- Down/ Up. Please select the one that meets your mounting preference before purchasing.
Mount Down- Model No. HKSE90D (see bracket solutions)
Mount Up- Model No. HKSE90U
Note:
- This headlight can ONLY be charged through 5 to 16V DC power
- Do not charge via an AC power source (e.g., a dynamo)
- Connecting to power supplies above the voltage limit may cause damage to the lamp
- The light does not feature a switch, it is controlled via the e-bike system
SPECIFICATION
| Model Name | SE-90 |
| Model No. | HKSE90D/ HKSE90U |
| Light Output | 90 Lux |
| Optical Technology | MTi |
| Light Source | LED *1 |
| Input Voltage (DC) | 5 ~ 16V |
| Power Consumption | 3.2W |
| Cable Diameter | ø4mm |
| Cable Length | 450mm/1400mm |
| IP Rating | IP56 |
| Operating Temperature (°C) | -25 ~ +70 |
| Material | Plastic |
| Weight (et. cable) | 66g |
| Dimension (WxHxL) | ø43.5 x 49mm |
| Reflector (Optional) | RF1 |
| Compliance | RoHS/CE/Prop 65 |
| Type of Approval | StVZO-K & ISO Compliance |
| Approval Number | ~ K1697 |
SYSTEM COMPATIBILITY
System Compatibility- Download.
